| Product overview
The network analyzer is equipped with multi-channel Gigabit Ethernet interfaces, which can generate configurable Ethernet test packets and provide test signal sources for the communication network. The capacity of the communication network and the performance of the communication network under different communication pressures can be evaluated by adjusting Ethernet data flow and inserting malformed Ethernet data packets and combined with various test statistical functions of the network tester. Ethernet tester provides the functions of protocol emulation and performance test of 2-3 layers of Ethernet, even 2-7 layers of Ethernet by using audio and video analysis software, so that it can meet the requirements of testing in R&D, experiment, quality control and mass production.
Network Analyzer
| Product function
● Test the throughput of communication network
● Test the loss rate of statistical frames
● Test the delay between communication network nodes
● Test the broadcast rate of broadcast frames
● Create malformed data packets and test the error frame filtering ability of communication nodes
● Capture and store network data, decode the data and analyze the protocol
● Simulate and generate Ethernet data packets with various configurable protocol fields
● Repackage and forward the received data packet
● Ethernet data packet filling test with adjustable rate
| Main technical indicators
No. | Indicator name | Technical indicator |
1 | Number of ports | Support 1-32 Gigabit Ethernet ports |
2 | Interface standard | 10/100/1000BASE-T |
3 | Port data rate | Each Ethernet port reaches 1,000 Mbps |
4 | Minimum value of network delay test | 1.5uS |
5 | Test message editing | Edit message content, message type, source MAC, destination MAC, source IP, destination IP, source port, destination port, checksum, etc. |
6 | Test data generation mode | Natural sequence, random sequence, manual editing |
7 | Send mode | Single transmission, cyclic transmission, triggered transmission |
8 | Error frame | Length error, frame header error, check error |
9 | Data capture | Check information of 32 network ports, and select one or several network ports for data capture |
10 | Data frame filtering rules | Including ip, port, udp, ip host, not udp, etc. |
11 | Hierarchical parsing of OSI model of data frame | Conduct hierarchical parsing from bottom to top for protocols according to the Ethernet data fields |
Network analyzer control software interface
| Applications
Self-organizing network
Bee colony UAV data link
Ship networking communication
Radio networking
